19-23 Ford Ranger 2.3L V6 Flowmaster 717997 Flow FX Cat-Back Exhaust System

Flowmaster 717997 Flow FX Cat-Back Exhaust System

Part Number: 717997

The Flowmaster 717997 Flow FX Cat-Back Exhaust System is engineered for 2019-2023 Ford Ranger models equipped with the 2.3L engine, delivering a performance-focused upgrade with improved exhaust flow, aggressive styling, and a deep moderate-to-aggressive exhaust tone. Designed with durable 409 stainless steel tubing and a Flow FX straight-through muffler, this system helps maximize exhaust efficiency while providing long-lasting corrosion resistance for daily driving and off-road applications. The dual same-side exit configuration features black stainless steel tips that add a custom appearance while maintaining a clean factory-style fit. With potential gains of up to 8 horsepower and 12 lb-ft of torque at the rear wheels over stock, this cat-back exhaust system is a premium choice for Ford Ranger owners seeking enhanced performance, sound, and appearance.

Key Features

• Designed specifically for 2019-2023 Ford Ranger models with the 2.3L engine.
• Flow FX straight-through muffler design provides improved exhaust flow and an aggressive-to-moderate performance sound.
• Constructed from durable 409 stainless steel tubing for strength and corrosion resistance.
• Features 3.00-inch inlet piping transitioning to dual 2.50-inch mandrel-bent exhaust tubing.
• Dual 3.50-inch black stainless steel exhaust tips with black ceramic coating provide a custom performance appearance.
• Uses factory hanger locations for a secure, OEM-style installation.
• Includes necessary clamps, hardware, and installation instructions.
• Designed as a complete cat-back exhaust system without catalytic converter replacement.

Benefits

• Improves exhaust gas flow to support increased performance potential with gains of up to 8 horsepower and 12 lb-ft of torque at the rear wheels over stock.
• Enhances the Ford Ranger driving experience with a deeper, more aggressive exhaust note while maintaining street-friendly sound levels.
• Provides improved durability compared to standard exhaust components with stainless steel construction.
• Creates a more customized truck appearance with dual black exhaust tips.
• Offers a straightforward installation process using existing factory mounting locations.
• Backed by Flowmaster's Lifetime Limited Warranty for added product confidence and long-term protection.

Product Specifications

• Brand: Flowmaster
• Part Number: 717997
• Product Type: Cat-Back Exhaust System
• Exhaust Series: Flow FX
• Material: 409 Stainless Steel Exhaust Tubing and Muffler
• Exhaust Tip Material: 304 Stainless Steel
• Finish: Natural Stainless Steel
• Exhaust Tip Finish: Black Ceramic Coating
• Exhaust Tip Color: Black
• Exit Style: Dual Out Same Side
• Exhaust Tip Quantity: 2
• Exhaust Tip Diameter: 3.50 inches
• Exhaust Tip Length: 7.45 inches
• Main Pipe Diameter: 2.50 inches
• Muffler Inlet Diameter: 3.00 inches
• Muffler Outlet Diameter: 2.50 inches
• Muffler Body Dimensions: 14.00 inches length x 9.00 inches width x 4.00 inches height
• Muffler Type: Absorption Straight-Through Design
• Sound Level: Aggressive / Moderate
• Mounting Type: Factory Hangers
• Clamping Type: Flat Band
• Clamps Included: Yes
• Catalytic Converter Included: No
• Emission Code: 5
• UPC: 090127818701

Install Difficulty level

The Flowmaster 717997 Flow FX Cat-Back Exhaust System is designed for an easy installation using factory hanger locations and included hardware. Installation can typically be completed in approximately 1-2 hours with basic hand tools, making it a practical upgrade for experienced do-it-yourself installers and professional shops alike.

Vehicle Fitment

• 2019-2023 Ford Ranger SuperCrew Cab 5-ft. Bed – 2.3L Engine
• 2019-2023 Ford Ranger SuperCab 6-ft. Bed – 2.3L Engine
