09-14 Ford F-150 2WD Maxtrac 903141F 4in Lift Blocks & U-Bolts w/ Rear FOX Shocks

09-14 Ford F-150 2WD Maxtrac 903141F 4in Lift Blocks & U-Bolts w/ Rear FOX Shocks

If you are looking for a simple and effective way to lift the rear end of your 2WD Ford F-150 without breaking the bank, look no further than the Maxtrac 903141F 4in Lift Blocks & U-Bolts w/ Rear FOX Shocks. This kit comes with everything you need to achieve a 4-inch rear lift, including high-quality lift blocks, u-bolts, and FOX shocks. The lift blocks are made of cast iron for durability and strength, and the u-bolts are zinc coated for corrosion resistance. The FOX shocks are designed to provide superior performance and ride quality, with a monotube design, aluminum body, and external reservoir. Whether you want to level your truck, fit larger tires, or improve your off-road capability, the Maxtrac 903141F 4in Lift Blocks & U-Bolts w/ Rear FOX Shocks is the perfect solution for your 2WD Ford F-150.

Key Features

• 4-inch rear lift kit for 2WD Ford F-150 without factory blocks
• Includes lift blocks, u-bolts, and FOX shocks
• Lift blocks are made of cast iron for durability and strength
• U-bolts are zinc coated for corrosion resistance
• FOX shocks are monotube, aluminum, and have external reservoirs
• Made in the USA

Benefits

• Easy and affordable way to lift the rear end of your truck
• Levels your truck and improves its stance
• Allows you to fit larger tires and wheels
• Enhances your off-road performance and capability
• Improves your ride quality and comfort
• Comes with a limited lifetime warranty on hard parts and a 1-year warranty on shocks

Product Specs

• Rear lift height: 4 inches
• Rear lift method: lift blocks and u-bolts
• Rear shocks: FOX 2.0 Performance Series
• Rear shock length: 26.1 inches extended, 16.15 inches collapsed
• Rear shock travel: 9.95 inches
• Rear shock body diameter: 2 inches
• Rear shock reservoir diameter: 2.5 inches
• Rear shock valving: 50/70
• Rear shock mount: eyelet/eyelet
• Rear shock color: silver
• Lift block material: cast iron
• Lift block size: 4 inches
• U-bolt material: steel
• U-bolt size: 9/16 x 3.5 x 12.5 inches
• U-bolt finish: zinc coated

Install Difficulty Level

Installing the Maxtrac 903141F 4in Lift Blocks & U-Bolts w/ Rear FOX Shocks is a relatively easy and straightforward process that can be done in your driveway or garage. You will need some basic tools, such as a jack, jack stands, wrenches, sockets, and a torque wrench. The installation time may vary depending on your skill level and experience, but it should take no more than 2 hours. You will need to remove the rear wheels, lower the axle, remove the stock shocks, install the lift blocks and u-bolts, install the FOX shocks, and reinstall the wheels. You may also need to adjust the brake lines and the parking brake cable to accommodate the lift. After the installation, you should check the alignment and the suspension components for proper fitment and clearance. You should also re-torque the u-bolts after 500 miles of driving.

Vehicle Fitment

The Maxtrac 903141F 4in Lift Blocks & U-Bolts w/ Rear FOX Shocks is designed to fit the following vehicles:

• 2009-2014 Ford F-150 2WD without factory blocks
• Engine: 3.5L V6 EcoBoost, 3.7L V6, 4.6L V8, 5.0L V8, 5.4L V8, 6.2L V8

If you have any questions about this product or want to report any inaccuracies in this product description, please contact the MPT Performance experts at (407) 636-7077 or by email.
